Brace Yourself - Firewal and NAT is coming

In previous post https://wojcieh.net/vyatta-router-running-on-vmware-workstation-part-1/ we configured basic network connectivity between two networks. Today we will enable NAT, Firewall and DNS.

NAT

Configuring NAT on Vyatta is quite simple. To do it type following commands:

  • set nat source rule 10 outbound-interface eth0
  • set nat source rule 10 source address 10.0.0.0/24
  • set nat source rule 10 translation address masquerade
  • set nat source rule 10 description “LAN to WAN”

Firewall

In my case I decided to use simple firewall rules based on zones. At the beginning it might be difficult to understand but if you will spend a while it should be crystal clear.

First part is to create firewall rules – I used WAN_TO_LAN and LAN_TO_WAN rules.

 WAN_TO_LAN

  • set firewall name WAN_TO_LAN
  • set firewall name WAN_TO_LAN default-action drop
  • set firewall name WAN_TO_LAN rule 10 action accept
  • set firewall name WAN_TO_LAN rule 10 protocol all
  • set firewall name WAN_TO_LAN rule 10 state established enable
  • set firewall name WAN_TO_LAN rule 10 state related enable

Here you see how rule WAN_TO_LAN should look like in configuration.

name WAN_TO_LAN {
default-action drop
rule 10 {
action accept
protocol all
}
}

LAN_TO_WAN

  • set firewall name LAN_TO_WAN
  • set firewall name LAN_TO_WAN default-action drop
  • set firewall name LAN_TO_WAN rule 10 action accept

Here you see how rule LAN_TO_WAN should look like in configuration.

name LAN_TO_WAN {
default-action drop
rule 10 {
action accept
}
}

Zone policies

Now we will create zones – in my case WAN and LAN and we will assign them to apriopriate ethernet interfaces.

  • set zone-policy zone WAN
  • set zone-policy zone WAN description “WAN”
  • set zone-policy zone WAN default-action drop
  • set zone-policy zone WAN interface eth0
  • set zone-policy zone LAN
  • set zone-policy zone LAN description “LAN”
  • set zone-policy zone LAN default-action drop
  • set zone-policy zone LAN interface eth1

Assign firewall to zones

This one is tricky – read carefully syntax of commands.

WAN firewall – set zone-policy zone WAN from LAN firewall name LAN_TO_WAN

LAN firewall – set zone-policy zone LAN from WAN firewall name WAN_TO_LAN

Here you see how zone WAN should look like.

default-action drop
description WAN
from LAN {
firewall {
name LAN_TO_WAN
}
}
interface eth0

Here you see how zone LAN should look like.

default-action drop
description LAN
from WAN {
firewall {
name WAN_TO_LAN
}
}
interface eth1

DNS configuration

DNS configuration is quite simple. In order to make it work enter following commands:

  • set service dns forwarding name-server IP (In my case it is 192.168.255.254)
  • set service dns forwarding listen-on eth1

In order to really test it from Domain Controller I set forwarded to Vyatta LAN IP – 10.0.0.1 and I deleted all root hints.

EOT

Wow – this was really long post. I hope you will find it really usefull and all will work in you environment as well.
